CRC-55tPET Dose Calibrator

CRC – 55tPET Dose Calibrator

Increases the maximum activity range for high energy PET isotopes

Category: Tags: , , , , ,

Description

The CRC®-55tPET Dose Calibrator gives you the ultimate features in the industry’s finest package. The CRC®-55tPET Dose Calibrator is designed to meet the demands of your department with accuracy and ease of operation. Reduced chamber pressure and increased bias voltage increases the maximum activity range for high energy PET isotopes.

The CRC®-55tPET provides a menu driven, touch screen interface that is easy to learn and use. The improved user interface contains an improved graphic color display, making operation and usage easier than ever. The unit provides 28 programmable keys. The user can select from over 80 nuclides by simply selecting the nuclide symbol on the touch screen interface.

Other capabilities include storage of reference sources in memory that automatically decay corrects for today’s time and date. Automated quality control tests and self-diagnostics are built-in with automatic zero and background subtraction making the CRC®-55tPET exceptionally easy to use.

Features

Features

  • 8” VGA touch screen color display
  • USB/PC Communications
  • Software upgrade via USB or Flash Drive
  • USB printer capability
  • Chamber plug-and-play capability
  • 28 programmable nuclide keys
  • Built-in dose calibration, quality control and self diagnostics
  • Over 80 nuclides in memory
  • Automatic chamber QC including linearity
  • Hard copy records of data available from optional printer
  • Compatible with nuclear medicine information management systems via USB
  • 256 channel MCA with detailed spectrum for identification analysis
  • Well counter for wipe tests and laboratory tests
  • Lab tests include Schillings, Plasma and RBC volume
  • User-definable protocols for wipe testing
  • Automated well QC including Chi-Square and MDA
  • Manual and Automatic ROI
  • Includes a pre-set key for F-18 measurements
  • Reports: Well counter reports for autocalibration, system test, MDA, Chi-Square and laboratory tests are archived and searchable by date, type, land activity
  • Automated Linearity Testing and Geometry Testing

Specifications

Specifications

  • Ionization Chamber: Type: Thin wall, deep well; Fill Gas: 5 atm Ultra Pure Argon
  • Measurement Range: Type: Auto Ranging: Activity: 20 Curies of F-18; Resolution: 0.1 µCi (0.01 MBq), max.
  • Display Screen: Type: 8” VGA LCD Color Touch Screen Display; Format: Direct reading in Ci or Bq; Bq/Ci Reading: User selectable or fixed; Values Displayed: Nuclide name (Atomic symbol, Mass number), calibration number
  • Electrometer: Accuracy: Better than ± 2%; Linearity: Within ± 2%; Response Time: Within 2 sec., 4 to 16 sec. for very low activity samples; Bias Voltage: +500V
  • Repeatability of Measurement: Repeatability: Within ± 1% within 24 hours during which time the calibrator is continuously on all the time
  • Overall Accuracy: Accuracy Determined By: 1) Calibration for the specific nuclide and the sample configuration, 2) Accuracies of standard sources used for calibration of electrometer
  • Tests: Diagnostics: Full test of program, system memories; Daily: Auto Zero, Auto Background, Voltage Test, Data Check, Accuracy and Constancy; Enhanced: Linearity, Geometry
  • Nuclear Data: Nuclide Keys: 28 programmable keys; System Memory:
  • Over 80 nuclides (Cal number and half life)
  • Standard Source Data: System Memory: Co-57, Co-60, Ba-133, Cs-137, Na-22 Standard Sources
  • PC Port: Interface: RS-232 & USB; Compatibility: Standard Nuclear Medicine Management Systems
  • Printer (Optional): Interface: RS-232 and USB; Type: Epson Roll, Epson Slip or Okidata full size dot matrix; Printing Options: Full size test reports, measured results on tickets
  • Power Requirements: 100-240 VAC (50/60 Hz) 100mA

Measurements

  • Console Dimensions: Height: 24cm (9.5in); Width: 23cm (9.0in); Length: 27cm (10.5in); Weight: 3.4kg (7.5lb)
  • Chamber Dimensions: Height: 43.8cm (17.25in); Diameter: 17.2cm (6.76in); Weight: 13.6kg (30lb); Well Diameter: 7.0cm (2.75in); Well Depth: 26.7cm (10.5in); Cable Length: 3.7m (12ft)
  • Well Counter Dimensions: Height: 23.8cm (9.38in.); Diameter: 15.2cm (6in.); Weight: 6.9kg (15.2lb.); Well Diameter: 1.7cm (.67in.); Well Depth: 3.8cm (1.5in.); Cable Length: 2.7m (9ft.)
